Belimo AMB24-MFT is a non fail-safe damper actuator designed with Multi-Function Technology (MFT) for customizable control sequences. Delivering 180 in-lb (20 Nm) of torque, it operates on AC/DC 24 V and supports a modulating input of 2...10 V. The...

Belimo AMB24-SR is a modulating damper actuator providing 180 in-lb (20 Nm) of torque without a fail-safe mechanism. Operating on AC/DC 24 V, it supports a 2...10 V DC control input, allowing precise airflow modulation. Position feedback mirrors the...

The Belimo AMX120-SR is a non fail-safe damper actuator delivering a torque of 180 in-lb (20 Nm). It operates within a voltage range of AC 100–240 V at 50/60 Hz. The actuator accepts a modulating control input of 2–10 V DC and provides a feedback output...

Belimo AMX24-SR-T is a non fail-safe actuator providing 180 in-lb (20 Nm) torque. It operates on AC/DC 24 V with a modulating control input of 2...10 V. The actuator's running time is 150 seconds for 90° rotation. It features position feedback of 2...10...

Belimo CMB24-SR-R is a non fail-safe actuator delivering 18 in-lb (2 Nm) torque. It operates on AC/DC 24 V with a modulating control input of 2...10 V. The actuator's running time is 75 seconds for 90° rotation. It features position feedback of 2...10 V...

Belimo EFB24-S is a damper actuator providing 270 in-lb (30 Nm) torque with a spring return mechanism. It operates on AC/DC 24 V with On/Off control. The actuator's running time for motor operation is 150 seconds, with a fail-safe return time of less...

Belimo EFCX120-S N4 is a spring return actuator delivering 270 in-lb (30 Nm) torque. It operates on a wide voltage range of AC 100-240 V or DC 100-125 V, supporting On/Off control. The actuator's running time for motor operation is 150 seconds, with a...

Belimo EFX24-MFT is a configurable damper actuator providing 270 in-lb (30 Nm) torque with a spring return mechanism. It operates on AC/DC 24 V with a modulating control input of 2...10 V. The actuator's running time is 150 seconds for motor operation,...

Belimo FSAF120A-S is a fire and smoke actuator delivering 180 in-lb (20 Nm) torque with a spring return mechanism. It operates on AC 120 V with On/Off control and includes two SPST auxiliary switches. The actuator's running time for motor operation is 25...

Belimo FSLF120-FC is a fire and smoke actuator providing 30 in-lb (3.5 Nm) torque with a spring return mechanism. It operates on AC 120 V with On/Off control. The actuator's running time for motor operation is 15 seconds per 90°, with a fail-safe return...

The Belimo AFBUP-X1 is a spring return valve actuator designed for On/Off control. It operates on a wide voltage range of AC 24...240 V or DC 24-125 V. The actuator's running time for motor operation is 150 seconds, with a fail-safe return time of less...

The Belimo AFB24-SR is a modulating damper actuator providing 180 in-lb (20 Nm) torque with a spring return mechanism. It operates on AC/DC 24 V with a control signal range of 2...10 V. The actuator offers position feedback of 2...10 V. The running time...

The Belimo AMQX24-1 is a configurable damper actuator delivering 140 in-lb (16 Nm) torque without fail-safe functionality. It operates on AC/DC 24 V with On/Off control. The actuator's running time is 150 seconds for 90° rotation. It features a manual...

The Belimo AFB24-S is a damper actuator providing 180 in-lb (20 Nm) torque with a spring return mechanism. It operates on AC/DC 24 V with On/Off control. The actuator's running time for motor operation is 150 seconds, with a fail-safe return time of less...

The Belimo FSTF24 is a fire and smoke actuator offering 18 in-lb (2 Nm) torque with a spring return mechanism. It operates on AC/DC 24 V with On/Off control. The actuator's running time for motor operation is 75 seconds, with a fail-safe return time of...

The Belimo AHQB24-MFT-100 is a linear damper actuator providing a force of 45 lbf (200 N) without fail-safe functionality. It operates on AC/DC 24 V with a modulating control input of 2...10 V. The actuator's running time is 150 seconds for full stroke...

The Belimo EFX24-S is a configurable damper actuator delivering 270 in-lb (30 Nm) torque with a spring return mechanism. It operates on AC/DC 24 V with On/Off control and includes two SPDT auxiliary switches. The actuator's running time for motor...

The Belimo GKB24-MFT is a damper actuator providing 360 in-lb (40 Nm) torque with electronic fail-safe functionality. It operates on AC/DC 24 V and features Multi-Function Technology (MFT), allowing programmable control with an input range of 2...10 V...

Belimo AMX24-MFT is a non fail-safe damper actuator delivering 180 in-lb (20 Nm) torque. It supports AC/DC 24 V power and MFT customization for input control. The running time is 150 seconds, and the actuator includes an external push button for manual...

Belimo AMQB24-MFT is a non fail-safe damper actuator with 140 in-lb (16 Nm) torque. It operates on AC/DC 24 V and supports Multi-Function Technology (MFT), enabling configurable input signals. The running time is 150 seconds, with electronic overload...

Belimo AMB24-SR-T is a non fail-safe actuator delivering 180 in-lb (20 Nm) torque with a modulating input of 2-10 V. It operates on AC/DC 24 V and includes a manual override feature. Electrical connection is provided via terminals. The running time is...

Belimo CMB120-3 is a floating point actuator rated for 18 in-lb (2 Nm) torque. It operates on AC 100-240 V and is designed for applications requiring floating point control. The running time for a full stroke is 75 seconds. The actuator is designed for...

Belimo AMX24-MFT95 is a non fail-safe damper actuator rated for 180 in-lb (20 Nm) torque. It operates on AC/DC 24 V and supports configurable control inputs with MFT functionality, allowing customized operation. The actuator has a running time of 150...

Belimo AFX24-MFT is a configurable spring return damper actuator with 180 in-lb (20 Nm) torque. Operating on AC/DC 24 V, it utilizes Multi-Function Technology (MFT) to allow customizable control sequences. Running time is 150 seconds for motorized...

Belimo AFB24 is a spring return damper actuator rated for 180 in-lb (20 Nm) torque. It operates on AC/DC 24 V and supports On/Off control. The running time for motor operation is 150 seconds, while the spring return mechanism ensures fail-safe...

Belimo FSAFB24-SR is a fire and smoke actuator with a spring return mechanism delivering 180 in-lb (20 Nm) torque. Operating on AC/DC 24 V, it features a modulating control signal range of 2-10 V and includes two SPST auxiliary switches rated for 6 A...

Belimo AMX24-SR is a non fail-safe actuator providing 180 in-lb (20 Nm) torque. It operates on AC/DC 24 V with a modulating control input of 2-10 V and provides position feedback within the same range. The running time for 90° rotation is 150 seconds,...

Belimo EFX120-S is a spring return actuator delivering 270 in-lb (30 Nm) torque. It operates on a wide voltage range of AC 100-240 V or DC 100-125 V, supporting On/Off and Floating Point control types. The actuator has a running time of 150 seconds for...

The Belimo EFB24-SR is a modulating spring return actuator providing 270 in-lb (30 Nm) torque. It operates on AC/DC 24 V with a control signal range of DC 2-10 V. The actuator offers position feedback of DC 2-10 V. Power consumption is 11 W during...

The Belimo EFB120-S N4 is a spring return actuator delivering 270 in-lb (30 Nm) torque. It operates on a wide voltage range of AC 100-240 V or DC 100-125 V, supporting On/Off and Floating Point control types. The running time is 150 s for motor operation...
